Trival Antene

AD-17/C-1512-F — Tactical V/UHF Wideband Discone Antenna

VHF, U/VHF, UHF · Vertical
Less than 1 kW

Key specifications

Frequency band
VHF, U/VHF, UHF
Power handling
Less than 1 kW
Polarization
Vertical

Add this product to your quote to get price and delivery information.

Product type

Platform

Supplier

  • Trival Antene

Overview

The AD-17/C-1512-F is a wideband VHF/UHF discone antenna engineered by Trival Antene for field, tactical, and transportable applications. It features unique bendable tape elements that allow for rapid deployment from a compact portable bag.

Technical Summary

  • Frequency Range: 100 - 512 MHz
  • Maximum Power: 500 W CW
  • Polarization: Vertical
  • Gain: Typically 2 dB
  • Connector: N female

Operational Use Cases

Designed primarily for tactical communication networks, this antenna supports field deployments where quick operational readiness is critical. Its continuous 100 to 512 MHz wideband coverage facilitates seamless V/UHF communications without requiring multiple band-specific antennas.

Deployment Environments

Built for demanding field and transportable environments, the antenna elements are constructed from special bi-directional bendable tape covered with a protective plastic sleeve. The complete assembly stows safely inside a portable cylinder covered with a double-impregnated canvas bag.

Performance Metrics

The antenna operates continuously across the 100 to 512 MHz band and delivers a typical gain of 2 dB. It supports demanding transmit applications with a maximum power handling capacity of 500 W continuous wave (CW).

Setup & Portability

The disc and radial elements are permanently attached to the central antenna hub. This integrated design, combined with the flexible radiating elements, ensures the antenna is ready for deployment in a fraction of standard assembly time directly from its storage bag.

Compatibility

The system includes a mounting console that allows for installation on appropriate masts with outer diameters ranging from 25 mm to 60 mm. The antenna interfaces with standard RF cabling via an N female connector.

FAQs

How do I choose the right omnidirectional antenna?

Selection factors include transmit versus receive-only requirements, transmitter power, operating frequency, and mounting platform. Verify the specific gain, tolerated VSWR, and radiation characteristics required for the network design.

What does vertical polarization indicate?

Vertical polarization describes the vertical orientation of the radiated electric field. It requires alignment with vertically polarized antennas at other network nodes to minimize polarization mismatch loss.

How is the antenna mounted?

It includes an integrated mounting console designed for mast attachment. Verify that the intended mast has an outer diameter between 25 mm and 60 mm for proper securement.
