AD-27/V150-2512-HP — Ultra Wideband Mobile VHF/UHF Antenna

Overview

The AD-27/V150-2512-HP is an ultra wideband mobile VHF/UHF omnidirectional antenna covering the 20 to 1000 MHz frequency range. It is primarily designed for high RF power jamming applications, featuring robust composite radiating elements and a shock-absorbing base for demanding tactical environments.

Technical Summary

• Frequency Range: 20 to 1000 MHz (HF/VHF/UHF)
• Power Handling: 200 W to 400 W continuous (version dependent)
• Materials: Composite radiators, aluminum/plastic base, stainless steel spring
• Finish: Military green (RAL-6014) two-component UV-resistant paint
• Options: Integrated active GPS antenna

Operational Use Cases

• High RF power jamming operations
• Wideband mobile VHF/UHF communications

Deployment Environments

Designed for severe mechanical environments, this mobile antenna utilizes a stainless steel spring base to absorb shocks and vibrations. The composite radiating elements ensure durability and strength under harsh operating conditions.

Performance Metrics

• Frequency Coverage: 20 to 1000 MHz
• Continuous Power Handling: 200 W to 400 W

Setup & Portability

The antenna base features four mounting holes equally spaced on a standard NATO 4.5-inch (114.3 mm) circle. Alternative base plate dimensions are available upon request to accommodate different mounting requirements.

Compatibility

Mechanically compatible with standard NATO 4.5-inch four-hole vehicle mounting interfaces. Verify specific amplifier compatibility against the 200 W to 400 W continuous power handling rating.

FAQs

• How do power handling and VSWR affect tactical antenna selection? Choosing an antenna that supports the maximum continuous power and tolerable VSWR of the transmitter is critical for aerial survival and prevents reflected power from damaging the amplifier.
• What mounting considerations apply to tactical antennas? The size, weight, and mounting interface determine an antenna's suitability for a specific platform. Verify the manufacturer's mounting dimensions, such as NATO standard bolt circles, to ensure mechanical compatibility.
• What is AD-27/V150-2512-HP — Ultra Wideband Mobile VHF/UHF Antenna used for? AD-27/V150-2512-HP — Ultra Wideband Mobile VHF/UHF Antenna is categorized as Omni Antenna.
• Problems we solve: how do we narrow antenna choices? Balancing operating bands, coverage needs and mounting space can make antenna selection difficult. Share those constraints with Cyntony to compare candidate antennas and identify what needs manufacturer confirmation (Our process).
• Outcomes we deliver: what comes from working through the requirements? The practical outcome is a requirements-led set of product options to evaluate with Cyntony. Confirm performance, compatibility and any service scope for your configuration before selection (Our process).

Video Notes

A brief demonstration showing the flexibility of the stainless steel shock-absorbing spring during simulated vehicle movement would effectively highlight the product's ruggedness for mobile deployments.
