LinkAlign-360AZR-20 — Auto Acquisition Antenna Positioner

Overview

The LinkAlign-360AZR-20 is a Power Over Ethernet (PoE) auto-acquisition antenna positioner designed for microwave line-of-sight communications. It features built-in GPS and a digital compass to automatically point and peak directional antennas rapidly and accurately.

Technical Summary

• Payload Capacity: Up to 90 lbs (40.8 kg)
• Azimuth Range: Full 360°
• Power and Control: Power Over Ethernet (PoE) with web-based UI
• Sensors: Built-in GPS and digital compass

Operational Use Cases

• Automated pointing and peaking for directional antennas
• Microwave line-of-sight communication links
• Integration with U.S. and NATO forces Band III, Band III+, and Band 4 radio systems

Deployment Environments

Designed for field deployment and transport, supporting optional transit cases. It can be installed in various operational environments using optional tripods or tabletop mounts.

Performance Metrics

• Maximum Payload: 90 lbs (40.8 kg)
• Azimuth Coverage: 360°

Setup & Portability

Initial configuration and operation are managed through a full-featured web-based user interface featuring a stored locations database for quick recall. Portability and deployment are supported by optional transit cases, tripods, tabletop mounts, and manual joystick controllers.

Compatibility

The positioner interfaces directly with U.S. and NATO forces Band III, Band III+, and Band 4 line-of-sight radio systems. It accommodates various payloads via optional radio adapter brackets, antenna adapter brackets, and polarization rotators.

FAQs

• How does an auto-acquisition positioner establish a line-of-sight link? Positioners typically use an embedded controller, GPS, and a digital compass for initial pointing. Once roughly aligned, the system utilizes software to interact with the radio's signal strength for a final automated peak to maximize data rates.
• What is the benefit of a stored locations database? A stored locations database allows the user interface to quickly recall known target coordinates. This facilitates rapid repositioning and faster link acquisition before initiating the final radio signal strength peaking process.
• How is the positioner powered and controlled? The LinkAlign-360AZR-20 utilizes Power Over Ethernet (PoE) for both power and network connectivity. Control is managed through a full-featured web-based user interface, with optional joystick accessories available for manual positioning.
• Problems we solve: where do we start with incomplete requirements? An incomplete specification can make product selection difficult. Start by sharing the task, operating environment and known constraints with Cyntony so the team can help define what to verify and which options are worth discussing (Our process).
• Outcomes we deliver: what comes from working through the requirements? The practical outcome is a requirements-led set of product options to evaluate with Cyntony. Confirm performance, compatibility and any service scope for your configuration before selection (Our process).
