RM-2450-2K-XW — Wearable Mesh Rider Radio (2.4 GHz)

Overview

The RM-2450-2K-XW Wearable Mesh Rider Radio provides private wireless networking and dynamic mesh capabilities for connected workers. Operating in the 2.4 GHz band, it enables tactical teams to collaborate by streaming encrypted voice, video, and data over a fast, low-latency network.

Technical Summary

• Frequency Band: S-Band (2400-2482 MHz)
• Throughput: Up to 100 Mbps
• Encryption: FIPS Certified AES 256- and 128-bit
• Waveform: Interference-resistant COFDM
• Power Output: 1.0 W maximum RF power at SMA port

Operational Use Cases

This radio is ideal for tactical communications and secure data links, enabling team collaboration through real-time voice and HD video streaming. It serves as a node on a self-healing mobile mesh network and is also available in an OEM form factor for embedded integration.

Deployment Environments

Engineered for difficult RF environments, this system maintains robust link quality during tactical field operations requiring reliable, continuous communication.

Performance Metrics

• Embedded Antenna Range: Up to 1 km for HD video streaming
• Maximum Range: Field tested >100 km (when paired with high-gain external antennas)
• Data Rate: Up to 100 Mbps
• Latency: Ultra-Reliable Low Latency Channel (URLLC) for Command and Control

Setup & Portability

Designed to be conveniently carried in handheld or manpack configurations. It features embedded antennas for immediate use and external ports for connecting high-gain antennas to extend range.

Compatibility

The device uses WiFi to seamlessly bridge commercial tablets and smartphones onto the secure mesh network. It can be powered by standard host tablets or standards-based USB battery banks.

FAQs

• What is the purpose of the COFDM technology in this radio? COFDM provides interference resistance to maintain link quality in difficult RF environments. It supports the transmission of high-bandwidth data across the dynamic mesh network.
• What encryption standards does the mesh network support? The system utilizes FIPS-certified AES 256-bit and 128-bit encryption. Verify that these specific standards meet your operational security and compliance requirements before deployment.
• Can external antennas be integrated for extended range? The device includes external antenna ports for integrating high-gain antennas. When selecting external directional or omnidirectional antennas, verify compatibility with the radio's connectors and 2.4 GHz frequency.
• Problems we solve: where do we start with incomplete requirements? An incomplete specification can make product selection difficult. Start by sharing the task, operating environment and known constraints with Cyntony so the team can help define what to verify and which options are worth discussing (Our process).
• Outcomes we deliver: what comes from working through the requirements? The practical outcome is a requirements-led set of product options to evaluate with Cyntony. Confirm performance, compatibility and any service scope for your configuration before selection (Our process).
